Features

(1) The carrying load is large, which can carry more than 40 tons;

(2) Adopt comprehensive control, the system operation performance is stable and reliable, and it is convenient to integrate into the user system;

(3) It can be equipped with an automatic temperature control device to ensure normal operation in a low temperature environment (optional);

(4) It has the functions of ascending, descending and stopping;

(5) It has a manual operation mode. In the event of a power outage or failure, the raised roadblock cover can be manually operated to lower the raised roadblock cover to a horizontal position, so that the vehicle can be released and the road can be restored;

(6) The system linkage control can be linked to the crossbar barriers or other controls.

Control method (1) The self-equipped control method of the system as long as it is: remote control, wire control;

(2) The remote control distance is 10000mm under unobstructed conditions, and greater than 5000mm under obstructed conditions.

(3) The wire control position is mainly installed on the desk or wall of the duty room.

System operation description

(1) Vehicle enters-stop to the target point and wait for identity confirmation-roadblock machine lowers-vehicle passes-roadblock machine rises

(2) The vehicle leaves-stops to the target point and waits for inspection-the roadblock machine is lowered-the vehicle leaves-the roadblock machine is raised

(3) Emergencies-under special circumstances or dangerous situations-get instructions-temporarily raise or lower the roadblock machine
